DSLR Full Spectrum Modifications by Hap Griffin

Would you like to be able to use your Canon DSLR for not only normal daylight photography, but also astronomical photography AND IR photography?  With a "Full Spectrum" modification, your DSLR becomes a Triple-Use camera, optimized for your current application with external or clip-in filters.



Normal Photography With Astronomik OWB Clip-In Filter Astrophotography with Astronomik L Clip-In Filter IR Photography with Astronomik Pro-Planet 742 Clip-In Filter

The New Astrodon Full Spectrum Option 2 modifications are available NOW!
Examples of IR photography with a Full Spectrum modified camera can be seen HERE.


Available Modification Options:

Canon Camera Option 2 (Full Spectrum)

Digital Rebel 300D No
Digital Rebel 350XT No
Digital Rebel 400D/XTi Yes
Digital Rebel 450D/XSi Yes
Digital Rebel 1000D/XS Yes
Digital Rebel 500D/T1i Yes
Digital Rebel 550D/T2i Yes
Digital Rebel 600D/T3i Yes
Digital Rebel 650D/T4i Yes
Digital Rebel 700D/T5i Yes
Digital Rebel 1100D/T3 Yes
Digital Rebel 1200D/T5 Yes
5D No
5D Mk II No
7D Yes
6D No
10D No
20D No
30D No
40D Yes
50D Yes
60D Yes


Full Spectrum Modification Details:

Stock Canon DSLR's built in the last several years contain two filters between the lens and the imaging sensor...an IR filter with the main purpose of blocking IR light and establishing the camera's color balance, and a section of glass used for the "dust cleaner" function that also blocks some IR light.  In order to open up the sensor's full spectrum capabilities, BOTH of these filters must be removed.  However, these filters also slow the light down in its path between the lens and the sensor, so when they are removed, the light will not come to focus properly on the front surface of the sensor.  To remedy this, we replace the two filters with one single clear filter that has the exact equivalent optical thickness of the combined two removed filters.  This restores the proper lens to sensor distance and keeps the camera's auto-focus in calibration.  There are other clear glass filters on the market, but they do not accurately replicate the original optical distance and the sensor position much be altered to return the auto-focus to calibration.  This is a tedious operation requiring great precision.  Only the Astrodon AD40Clear filter has the exact thickness and refractive index required to keep your auto-focus calibrated WITHOUT adjusting the stock sensor position.  This makes it much easier for the do-it-yourself modifier.

In the stock camera, the two filters present four optical surfaces (not counting the lens and the sensor itself) that the light must pass through.  Each surface can cause reflections which become apparent with bright off-axis stars in astrophotography.  With the Astrodon Full Spectrum modification, the two existing filters are replaced by one, presenting only two surfaces...each of which is coated with the famous Astrodon hard oxide anti-reflection coating.  The clear filter is not made of ordinary float glass, but strai-free fused silica for maximum performance.



The AD40Clear filter presents greater than 95% transmission from 430 nm (UV) to 1100 nm (IR).  This provides a camera that can be used for multiple purposes and optimized for each purpose by external or clip-in filters.

For instance, for normal daylight or indoor photography the spectrum must be restricted to that of visible light with a response curve that closely replicates that of the original stock filters.  An external lens mounted filter such as the X-Nite CC1 could be used.  This would require a separate filter for each lens in your bag, and possibly multiple sizes to fit your different lenses.  A more economic and convenient solution would be a single clip-in original white balance filter such as the Astronomik OWB
which clips into the front of the lens opening in the camera and works with all Canon EF lenses you may have (the EF-S lenses will not work with clip-in filters).  A custom white balance cannot be used to color correct the full spectrum modified camera for normal use since the spectral response is TOO wide for a custom white balance to work...an actual optical correction filter must be used.  Because the full spectrum modification removes the "anti-aliasing low pass filter" used for the dust cleaner function, images are of the highest level of detail that your camera is capable of capturing, but the automatic dust cleaning function will no longer be available.

For astronomical purposes, the extended UV and IR response must be limited, while preserving all of the wavelengths important for astronomical targets.  This is because telescopes and lenses are not corrected for such a wide spectrum.  They are optimized to accurately focus visible light and light with much shorter or longer wavelengths will be out of focus, causing "star bloating".  Systems that contain refractive elements are particularly bad about this problem, known as "chromatic abberation".  Even expensive APO refractors are not well corrected into the IR spectrum.  A standard astronomical UV/IR blocking filter does the job nicely.  Examples would be the Baader 2" UV/IR blocker that could be put anywhere in the imaging chain.  A clip-in filter such as the Astronomik L could also be used and would be a good solution for wide-field photography using normal camera lenses.  In light polluted areas, the Astronomik CLS-CCD would be a good choice for reducing the effects of urban light pollution.  SInce the camera is sensitive to the entire spectrum, narrowband filters such as Hydrogen-alpha, S2, O3, etc. can be used to good effect.  Some astrophotographers are now experimenting with UV and IR imaging and the full spectrum modification provides a perfect platform for this work.

IR photography is becoming very popular and the full spectrum modification provides a camera that is wide open for experimenting with this mode.  By using an external lens mounted or clip-in IR filter that passes infrared light but blocks visible light, the world appears vastly different photographically.  The sky darkens and clouds become visible with much more contrast.  Foliage appears in shades of white.  Various processing techniques can be used to create other-worldly colored images.

All of this is now possible with a single camera!

Option 2 - Full Spectrum - IR Filter Replacement with Astrodon Clear Filter - $320.00 plus return shipping of customer's choice

By replacing both the IR filter and the front filter used for the dust cleaner function with an Astrodon clear filter of the proper thickness, the optical viewfinder calibration and autofocus with normal lenses is retained.  External or clip-in filters are used to customize the camera's response for the use at hand...astronomical, normal photography, or IR imaging.  In refractive astronomical optical systems (lenses, refractors, SCT's with refractive corrector plates, or any telescope with an integral or external focal reducer), an external IR block filter must be inserted in the imaging chain such as a Baader UV/IR Block or Astronomik L Clip-In Filter.  For normal daylight use with camera lenses, an external IR blocking and color correcting filter must be used such as the X-Nite CC1 filter or the Astronomik OWB Clip-In filter.  For IR photography, a lens mounted IR filter or an Astronomik Pro 742 IR Clip-In filter may be used.  Thus, with this modification and external filters, the camera becomes a triple-use device...astronomical, daylight and IR all in one!

For those who want to do the modification on their own, I offer the Astrodon AD40Clear filter by itself...

PLEASE NOTE:  When doing your own camera modifications, you void any remaining warranty on your camera and you take full responsibility for any damage done during the modification.  I will be happy to answer questions via e-mail but cannot be held responsible for any damages.  If you do not feel comfortable working on microelectronics and expensive and fragile CMOS sensors, I offer full modification service using quality Astrodon Inside filters.

Various web sites include instructions for modifying Canon DSLR's.  Please be aware that the AD40Clear filter replaces BOTH of the stock glass filters.  It should be mounted into the plastic IR filter holder in place of the stock IR filter.  The front dust cleaning filter should be removed and the camera's menu setting for automatic dust cleaning should be set to "disable".  When the AD40Clear replaces BOTH stock filters, the position of the sensor platform does NOT have to be altered.  In models with adjustable sensor platforms, be sure to carefully measure the height above the metal camera chassis of the sensor platform at all three adjustment screws with a dial micrometer or other instrument before the modification and return the sensor platform to the same position after modification.  It is critical that the platform be returned EXACTLY to its original position at all three adjustment screw locations or the focus and/or sensor collimation will suffer.  The adjustment can be done by counting fractions of a turn of each screw required to bottom out the adjustment and then adjusting the screws out by that same amount upon re-assembly, but I have found that method to be unreliable.  A dial-micrometer provides a much finer adjustment measurement accurate to within 0.001".

Description Price
(inc. US shipping)

Part # AD40Clear    For the Canon DSLR models listed above (one per customer - no resellers) $105.00
Priority International Shipping for customers in Canada (price reflects 2014 USPS postal rate increase)  $20.55
Priority International Shipping for all other non-US customers (price reflects 2014 USPS postal rate increase)  $24.75



IMPORTANT - PLEASE READ:

Be sure that you understand that these modifications will void any remaining manufacturer's warranty.  Not being a Canon dealer, I cannot warrant cameras that are sent into me for modification.  However, I test each camera before any work is done to detect any latent issues...if any are found, the camera will be returned un-modified.  I guarantee that you will receive your camera back in fully working condition, except obviously for the changes described above for your particular modification.  If you have any questions regarding my work or reliability, I would invite you to ask on any of the popular DSLR astrophotography discussion groups on the web.  I have performed well over 800 DSLR modifications and have a lot of satisfied users out there!

While modified cameras can be and are used for everyday photography using either external color correction filters or a custom white balance as described HERE, please be aware that these modifications fundamentally alter an important part of your camera's optical chain.  We are modifying your camera to make it function better for a specific application.  If you are using your camera for professional portrait work or similar applications where absolute stock color accuracy, pinpoint autofocus with normal lenses, and a pristine factory clean optical system are important, I would recommend obtaining a second camera to modify.  The prosumer line of Canon cameras do not offer significant advantages for astronomy over the less expensive and lighter weight models and I often recommend one of those lesser expensive models to dedicate to astrophotography rather than modifying the family DSLR for astronomical work.

Stringent precautions are taken during the modification process to avoid the deposit of any dust particles on the optical surfaces.  The sensor and filters are cleaned and checked as the modification is done and multiple test flat field images are taken and kept on file for every camera following each modification.  Occasionally, microscopic particles can find their way in or can work loose from the sticky tape filter gasket during shipment but can be completely removed from images with proper flat frame calibration as is normal for all astronomical photography.  Some models of cameras have the ability to map these microscopic spots and adjust for them so that they are not visible.

Be sure that you understand that the Full Spectrum modification requires that external or clip-in filters are required to tailor your camera to a particular application.  These filters are NOT supplied as part of the modification.

Every effort is made to salvage the original filters from the camera in good shape so that they can be replaced later if desired.  In most cases this is possible and the original filters will be returned to the owner.  However, in some models (the 400D/XTi in particular), the filter is securely glued in place and is almost always damaged in removal.


Payment in the form of a check or money order should be sent along with the camera to the address below along with a description of the modification option desired.  If you desire to use PayPal instead, please contact me at lgriffin@sc.rr.com before payment.  Please supply instructions on the desired return shipping method (insurance for the full value of camera is mandatory) and add sufficient funds to cover the cost.  I prefer to use USPS Priority mail for domestic shipping which generally runs $20 with insurance and delivery confirmation.  Turn-around time will depend on my work load, but should normally be less than a week once I receive your camera.  If you need a quick turnaround, please contact me at lgriffin@sc.rr.com before shipping the camera to check on my current lead time.  Also, contact me directly for information on other DSLR's as their modifications become available.

When shipping a camera, please include only the body (I have lenses, batteries, memory cards, etc. used for testing) and ship it to:

Hap Griffin
2295 Watersong Run
Sumter, SC 29150

Thank you for your interest!
Clear skies...
